Water heaters WH-1 and WH-2 connect to three-inch domestic cold water and domestic hot water piping equipped with line-size ball valves and balance valves. A three-quarter-inch ASME temperature and pressure relief valve discharges to a floor sink without trapping the piping. A vacuum breaker is provided at the water heater hose bibb drain, and units are set at a maximum temperature of 140 degrees Fahrenheit.
NOTES: 1. UNLESS OTHERWISE NOTED, ALL VALVES & FITTINGS SHALL BE LINE SIZE. USE BELL REDUCERS WHERE REDUCERS ARE REQUIRED. SEE PLANS FOR SIZES. 2. WATER HEATERS SHALL BE SET AT A MAXIMUM TEMPERATURE OF 140° F. WH-2 3"DCW 3"DHW 3"DCW 3"DHW 3/4" T & P ASME T & P RELIEF VALVE. PIPING SHALL NOT BE TRAPPED. DISCHARGE TO FLOOR SINK. WH-1 (TYP) BALL VALVE (TYP) BALANCE VALVE 3/4"DHWR 3/4" T & P PROVIDE VACUUM BREAKER AT WATER HEATER HOSE BIBB DRAIN. (TYP) SEE 3/P7.9 FOR ANCHORAGE DETAIL
