Suspended pipes are supported by a trapeze hanger consisting of a Superstrut welded double channel 1202 series or equal, secured with hanger rods, nuts, jam nuts, washer clamps, and pipe clamps sized as required. Transverse seismic bracing is provided per SMACNA guidelines using pre-punched structural support adjustable angle fittings. The entire trapeze and sway brace assembly anchors back to the structural concrete slab using concrete inserts or expansion anchors. Longitudinal bracing and seismic restraint spacing comply with the latest SMACNA mechanical and plumbing piping systems guidelines.
A PRE-PUNCHED STRUCTURAL SUPPORT ADJUSTABLE ANGLE FITTING (TYP) PIPE CLAMP (SIZE AS REQ'D.) PIPE (TYP.) HANGER RODS (TYP.) TRANSVERSE BRACING PER SMACNA SECTION A-A NUT JAM NUT ROD NOTE: 1. SEISMIC ANCHORAGE AND BRACING OF ALL PIPING AND EQUIPMENT SHALL BE IN ACCORDANCE WITH THE LATEST ISSUE OF "GUIDELINES FOR SEISMIC RESTRAINTS OF MECHANICAL SYSTEMS AND PLUMBING PIPING SYSTEMS" AS PUBLISHED BY SMACNA. 2. SPACING OF TRAPEZE HANGERS SHALL BE BASED ON THE CLOSEST SPACING REQUIRED BY THE APPLICABLE PRODUCT TRANSPORTED. 3. LONGITUDINAL BRACING SHALL BE PER SMACNA AT 80'-0" O.C. MAXIMUM. CONCRETE INSERT OR EXPANSION ANCHOR (TYP) STRUCTURAL CONCRETE SLAB WASHER CLAMP SUPERSTRUT WELDED DOUBLE CHANNEL 1202 SERIES, OR EQUAL.
