Waste and vent piping is routed through floors and walls with cleanouts installed per UPC 707.0 and 719.0. A sidewalk cleanout-to-grade features a cover plate and waste pipe secured with typical pipe clamps, maintaining a 1% slope on larger horizontal piping. A wall-mounted cleanout with a cover plate connects to the waste and vent stack at the finish floor level, utilizing a 2% slope for 2-inch horizontal piping.
NOTE: 1. INSTALL PER UPC 707.0 AND 719.0 2. HORIZONTAL PIPING THAT IS 2" TO BE 2% SLOPE AND PIPES 3" AND LARGER TO BE 1% SLOPE PER TABLE C 304.2 OF 2015 UPC. SIDEWALK COTG COVER PLATE WASTE PIPE CLAMP, (TYP) FINISH FLOOR 2% SLOPE 1% SLOPE SLOPE 2% SLOPE SLOPE WASTE COVER PLATE WCO VENT WALL
