A recessed hose bibb cabinet mounts within a wood-framed wall backed by double blocking for rigidity. A cold water supply pipe feeds the hose bibb through a three-quarter-inch stop valve. A non-removable vacuum breaker connects to the hose bibb inside the enclosure. A watertight seal is required between the bibb, box, stop, and box assembly. The cabinet box secures to the finished wall using quarter-inch screws spaced at three inches on center along all four sides.
2 1/2" 9-1/2" 2-3/16" HOSE BIBB (HB-1) RECESSED IN CABINET 3-1/4" 8" KEY NOTES VACUUM BREAKER (NON-REMOVABLE). COLD WATER SUPPLY. HOSE BIBB. DOUBLE BLOCKING TYPICAL. SECURE PIPE TO BEAM AT TWO PLACES FOR RIGIDITY. 1 3 2 4 1 2 5 6 7 3/4" SIZE STOP. FINISHED WALL. WATER TIGHT SEAL BETWEEN BIBB, BOX, STOP & BOX REQUIRED. 1/4" SCREW AT 3" O.C. ON FOUR SIDES. 5 7 6 8 8 5 3 4 5
