Suspended piping is supported by a threaded hanger rod secured with top and bottom nuts and washers to an adjustable J-hanger. A transverse angle brace connects to the structure and alternates sides on every brace. A vertical angle stiffener is added when the length exceeds the maximum shown on the pipe support schedule and is spot welded. Insulation is applied where specified. A pipe saddle is used on pipes two inches inside diameter and smaller.
1 - 4 - SPECIFICATIONS NOTE: ADJUSTABLE "J" APPLIES - SEE INSULATION WHERE "B-LINE" - B3690 HANGER. PIPE SADDLE "B-LINE" B3162 DETAIL APPLIES TO PIPES 2" I.D. AND SMALLER. TOP & BOTTOM NUT & WASHER SEE FOR CONNECTION TO STRUCTURE TRANSVERSE ANGLE BRACE. ALTERNATE SIDES EVERY BRACE. PIPING. SEE PLANS FOR SIZE AND LOCATION. THREADED HANGER ROD. FOR SIZE AND SPACING SEE 1. ADD VERTICAL ANGLE STIFFENER IF LENGTH IS GREATER THAN MAX. LENGTH SHOWN ON PIPE SUPPORT SCHEDULE REFER TO PIPE SUPPORT SCHEDULE FOR ADDITIONAL INFORMATION. 2. STIFFENER SHALL BE SPOT WELDED
