An uninsulated pipe of size per drawings is suspended by a standard clevis hanger secured with a bolt. A threaded hanger rod connects the clevis hanger to an eyebolt anchored into the support structure by others. The eyebolt satisfies section 1621 of the 2003 IBC, and the threaded hanger rods and spacing comply with the 2003 IPC with a maximum twelve-inch clearance.
USE EYEBOLT TO SATISFY SECTION 1621 OF THE 2003 IBC. THREADED HANGER RODS AND SPACED PER 2003 IPC WITH EYE BOLT SIZED 12" MAX SUPPORT STRUCTURE (BY OTHERS) STANDARD CLEVIS HANGER. UNINSULATED PIPE SEE DRAWINGS FOR SIZE. BOLT FOR CLEVIS HANGER. w (h 4
