A 400-series straight drapery track is suspended from a Unistrut bracket P2543 or equal, which is mounted to the inside face of a wall at a maximum spacing of five feet on center. Two fasteners secure each bracket into structural wall backing. A 400-series drapery track clamp connects the track to the bracket, holding a 400-series drapery carrier and a VA drape below.
CRITERIA. MOUNT DRAPE BRACKET EVERY 5'-0" MAX ON CENTER AT WALLS UNISTRUT BRACKET P2543 (OR EQUAL) 400 SERIES DRAPERY TRACK CLAMP 400 SERIES STRAIGHT DRAPERY TRACK 400 SERIES DRAPERY CARRIER VA DRAPE (2) FASTENERS PER BRACKET, INTO BACKING WALL BACKING (BY STRUCTURAL) INSIDE FACE OF WALL
