P-VTFN4 — Structural Member Support Detail with HSS and W-Shape

Structural · P-VTFN4

Structural Member Support Detail with HSS and W-Shape

About this detail

A hollow structural section connects to an underlying structural member with dimensions of 5 feet 5 1/8 inches and 1 foot 3 1/8 inches vertically, alongside horizontal offsets of 1 foot 10 1/4 inches and 2 feet 0 1/4 inches. The assembly includes reference tags 2N4, 564, FE-01, and 208 designating specific components and layout grid locations.

2N4 208 5' - 5 1/8" 1' - 3 1/8" 1' - 10 1/4" 2' - 0 1/4" 564 FE-01

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
