This drawing indicates plumbing clearance dimensions relative to structural framing elements. Dimensions of 1'-2 3/8 inches, 5'-2 3/8 inches, 1'-2 3/4 inches, and 2'-9 1/2 inches locate piping components from grid lines and structural profiles. Callout markers designate specific pipe tags and structural identifiers.
