A cast iron sanitary line connects to an eighth-bend riser terminating at finish grade with a brass cleanout plug featuring a countersunk head. A sixteenth-inch square concrete pad is trowelled smooth and edged around the upper bend just below grade. An eighth-bend is installed at the intersection if the cleanout occurs at the end of the line.
C.I. SANITARY LINE LENGTH TO SUITE 1/8" BEND IF CLEANOUT OCCURES AT END OF LINE 16" SQUARE CONC. PAD TROWEL SMOOTH AND EDGE SAN 1/8" C.I. BEND BRASS CLEANOUT PLUG W/ COUNTER SUNK HEAD FINISH GRADE
