A steel pipe lateral brace connects to a structural steel member using a Tolco Fig. 980 swivel sway brace fitting and a one-half-inch bolt with a nut and washer. The brace maintains an angle between forty-five and fifty-nine degrees relative to the support. A Tolco Fig. 4AL pipe clamp secures the opposite end of the brace to the main carrier pipe.
C L LONGITUDINAL ATTACHMENT STEEL PIPE LATERAL BRACE TOLCO FIG. 4AL PIPE CLAMP FOR SWAY BRACING NUT & WASHER 1/2" BOLT x 1" FIG. 980 SWIVEL SWAY BRACE FITTING 45° TO 59°
