A packaged triplex booster pump system includes suction and discharge pressure transducers, discharge pressure gauges, and factory-installed valves within the main assembly boundary. Three parallel pumps connect to three-inch domestic cold water piping with butterfly valves and Metraflex Cablesphere flexible connectors provided on both supply and discharge lines. A normally closed full line size bypass valve bridges the water supply in and out lines.
PT PT PACKAGED TRIPLEX BOOSTER PUMP SYSTEM - ALL VALVES AND EQUIPMENT SHOWN IN BOUNDARY FACTORY INSTALLED DISCHARGE PRESSURE GAUGE DISCHARGE PRESSURE TRANSDUCER SUCTION PRESSURE TRANSDUCER 3"DCW 3"DCW BUTTERFLY VALVE METRAFLEX CABLESPHERE FLEX CONNECTOR (TYP. 2) WATER SUPPLY IN WATER SUPPLY OUT FULL LINE SIZE BYPASS VALVE (N.C.)
