A gypsum cove ceiling meets a wall partition with a continuous cove light fixture and sound-absorptive ceiling panels. The vertical partition features a gypsum wallboard finish designated as VP-01, extending between Level 1 and Level 2.
LEVEL 2 15' - 1" LEVEL 1 - EAST - TOS 1' - 1" VP-01 7 A946P2 GYP COVE CEILING COVE LIGHT FIXTURE, SEE RCP FOR TYPE SOUND ABSORPTIVE CEILING LOBBY 145 1567.59 SF VEST 147 106.08 SF 4" 3 A925
