A floor sink installation is set flush with the surrounding finished floor. The floor sink grate top includes a maximum one-half inch opening in all directions. An indirect waste pipe discharges above the sink maintaining a one-inch minimum air gap. The sink body incorporates an anchoring flange with weepholes and is sealed with a caulk joint at the floor interface. Below the sink, a cold water supply connects to the trap via a half-inch connection, and a no-hub connection ties into the waste pipe.
FLOOR SINK GRATE TOP SET FLUSH WITH FINISHED FLOOR AND WITH 1/2" MAX. OPENINGS IN ALL DIRECTIONS. FINISHED FLOOR CONNECT 1/2"CW TO TRAP. NO-HUB CONNECTION WASTE PIPE CAULK JOINT INDIRECT WASTE 1" MIN. AIR GAP ANCHORING FLANGE WITH WEEPHOLES
