A pipe penetrates through a fire-rated wall or partition encased within a pipe sleeve. Any gaps between the sleeve and the wall or partition are sealed with cement. The assembly is also applicable to interior non-waterproof floor construction, while waterproof and other floor constructions require referencing project specifications. Pipe sleeves and escutcheons must be installed in accordance with the specifications article.
PIPE WALL OR PARTITION NOTE: 1. REFER TO SPECIFICATIONS ARTICLE ENTITLED "SLEEVES AND ESCUTCHEONS FOR PIPING." 2. THIS DETAIL ALSO APPLICABLE TO INTERIOR NON-WATER PROOF FLOOR CONSTRUCTION. FOR WATER PROOF FLOOR CONSTRUCTION AND OTHER FLOOR CONSTRUCTION SEE SPECIFICATIONS. PIPE SLEEVE CEMENT ANY GAPS BETWEEN SLEEVES AND WALL NO SCALE 3 PIPE THRU FIRE RATED PART. & WALL DETAIL
