This slab construction joint detail features a first pour and a second pour separated by a joint measuring one-eighth inch wide by one-quarter inch deep filled with sealant. The assembly is tied across the joint with one-inch diameter by one-foot four-inch long smooth round dowels spaced at twelve inches on center and centered in the slab thickness. The slab-on-grade thickness and reinforcing are specified per plan, bearing directly on a compacted sub-grade.
USE AS REQUIRED 1" X 1'-4" LONG SMOOTH ROUND DOWEL @ 12" O.C. CENTERED IN SLAB SLAB ON GRADE THICKNESS AND REINFORCING PER PLAN T.O. SLAB EL.: PER PLAN COMPACTED SUB-GRADE t 1/8" WIDE x t/4" DEEP JOINT WITH SEALANT SECOND POUR FIRST POUR
