An air conditioning unit is installed level on a unit curb above the roof, connecting to a copper condensate drain sized to the unit outlet. The drainage line incorporates a four-inch trap and a vent line installed with a slope. An external trap must be provided if not internal to the unit, per manufacturer requirements. The plumbing contractor is responsible for the condensate drains and preventing damage to the sheetrock ceiling from carryover problems.
AIR CONDITIONING UNIT COPPER CONDENSATE DRAIN UNIT OUTLET SIZE VENT SLOPE UNIT CURB ROOF INSTALL A/C UNIT LEVEL NOTE: 1. CONTACT A/C MANUFACTURER FOR PROPER CONDENSATE DRAINAGE. PROVIDE EXTERNAL TRAP IF NOT INTERNAL TO UNIT. THIS CONTRACTOR IS RESPONSIBLE FOR ANY DAMAGE THAT OCCURS TO THE SHEETROCK CEILING DUE TO CONDENSATE CARRYOVER PROBLEMS. 2. PLUMBING CONTRACTOR IS RESPONSIBLE FOR CONDENSATE DRAINS. 4" TRAP
