A twenty millimeter branch drops from the compressed air main through a twenty millimeter forty-five degree elbow and nipple to an isolation ball valve. An automatic moisture removal trap with a bowl guard mounts below the valve, routing condensate piping to the nearest floor drain.
20mm 45° ELBOW 20mm NIPPLE 20mm BALL VALVE AUTOMATIC MOISTURE REMOVAL TRAP WITH BOWL GUARD, PIPE TO NEAREST FLOOR DRAIN (FD-1). COMPRESSED AIR MAIN 4 5 6
