This hot water recirculation branch incorporates an automatic flow control valve with union body flanked by ball type shut-off valves for isolation. A strainer and check valve are integrated into the piping run to protect system components and prevent reverse flow. A temperature gauge plug is provided for system monitoring within the insulated pipe assembly. All connections and installations follow manufacturer recommendations and project specifications.
HOT WATER RECIRCULATION BRANCH AUTOMATIC FLOW CONTROL VALVE WITH UNION BODY; REFER TO FLOOR PLANS FOR FLOW RATE AND PIPE SIZE. TYPICAL BALL TYPE SHUT-OFF VALVE STRAINER CHECK VALVE REFER TO SPECIFICATIONS, SCHEDULES, AND NOTES FOR MORE INFORMATION. MAKE CONNECTIONS AND PROVIDE INSTALLATION PER MANUFACTURER'S PIPE INSULATION TEMPERATURE GAUGE PLUG
