Right side elevation of an underground interceptor tank set within a minimum eight-inch concrete grade. The assembly features a top diamond plate cover positioned over a foam seal, with a total width of twenty-four and one-quarter inches. Internal components and depth dimensions indicate an overall depth of thirty-two and one-quarter inches. An optional extension and side connection are also indicated with specific dimensional callouts.
