The cold water inlet connects via three-eighths-inch chrome-plated brass tubing fitted with chrome-plate escutcheons and quarter-turn chrome-plated stops. Filter cartridge housings are secured with mounting brackets anchored to the wall. Typical shut-off valves control flow into the system before routing to the ice machine.
MOUNTING BRACKETS FILTER CARTRIDGE HOUSING SHUT OFF VALVE (TYPICAL) ESCUTCHEON QUARTER TURN 3/8" CHROME PLATED CHROME PLATED STOP BRASS TUBING COLD WATER INLET CHROME PLATE TO ICE MACHINE ANCHOR TO WALL
