Hot and cold water mains feature individual shut-off stops connected to a Watts USG-B mixing valve set at 110 degrees Fahrenheit. The mixed water outlet routes upward to supply the faucet connections beneath the sink counter.
FLOOR CONNECTIONS TO FAUCET TOP OF COUNTER COLD WATER MAIN W/STOP SINK HOT WATER MAIN W/STOP WATTS USG-B MIXING VALVE SET AT 110°F
