A vertical pipe penetration through a cast-in-place concrete floor utilizes a sleeve sized to provide a two-inch annular space, supported by an Anvil Figure 261 riser clamp. A second detail features a core-drilled existing floor opening sized to provide a one-quarter-inch annular space, with a note requiring X-ray scanning of any post-tension decks prior to drilling. Both penetrations include caulking sealant where insulation does not occur and fire-stopping at all rated floors.
SEE FLOOR PLANS FOR PIPE SIZE FIRE-STOPPING AT ALL RATED FLOORS SEE FLOOR PLANS FOR PIPE SIZE FIRE-STOPPING AT ALL RATED FLOORS RISER CLAMP ANVIL FIG 261 CAULK SEAL WHERE INSULATION DOES NOT OCCUR CORE DRILL FLOOR SIZED TO PROVIDE 1/4" ANNULAR SPACE X-RAY ANY POST-TENSION DECKS CAULK SEAL WHERE INSULATION DOESN'T OCCUR SLEEVE THRU CAST-IN PLACE FLOOR SIZED TO PROVIDE 2" ANNULAR SPACE RISER CLAMP ANVIL FIG 261 CAST-IN PLACE SLEEVE
