Single Pipe and Trapeze Hanger Detail

Materials

Steel Metal (misc.)

Elements

Bracing

Connections

Bolted Connection

About this detail

A single pipe clevis hanger and trapeze hanger assembly are supported by threaded rod hangers and upper attachments. The single pipe configuration utilizes a B-Line B3100F clevis hanger with a 14-gauge zinc-coated saddle supporting a pipe up to 4 inches in diameter, secured with locking nuts and support nuts. The trapeze assembly incorporates a P1001 Unistrut channel spanning a maximum of 4 feet with a maximum weight capacity of 1,000 pounds, supporting up to three pipes via structural clamps or U-bolts. Seismic restraints feature quarter-inch diameter aircraft cables splayed at 45 degrees in four directions on single pipes and on both sides of the unistrut, adhering to specified maximum hanger spacings and transverse or longitudinal bracing intervals.
