Plumbing · P-P55YM

Sewer and Vent Isometric Plan

Materials

Elements

About this detail

A diagrammatic sanitary sewer and vent isometric piping layout runs alongside a floor drain and sink installation detail. The plumbing network includes one and one-half inch, two inch, and three inch sanitary sewer and vent lines with vent through roof connections, cleanouts, and fixture tags for water closets, lavatories, floor sinks, mop sinks, kitchen sinks, and drinking fountains. Piping mounted high in the gymnasium runs above the ceiling between purlins and requires coordination with architectural and structural trades. The floor drain installation specifies a top of grate set one-quarter inch lower than the top of concrete floor elevation, with a two inch diameter tail piece, a one-quarter inch trap primer line, and a one-quarter inch plywood template with a beveled edge installed at the floor drain.
