Domestic hot water and domestic cold water risers connect to a thermostatic mixing valve to supply tempered water to multiple lavatories along a common wall and counter top. The piping layout is shown in front and plan views relative to the wall and counter top.
MIXING VALVE DHW RISER DCW RISER TEMPERED WATER TO LAV TEMPERED WATER TO LAV TEMPERED WATER TO LAV TEMPERED WATER TO LAV TEMPERED WATER TO LAV MIXING VALVE DHW RISER DCW RISER TEMPERED WATER TO LAV FRONT VIEW WALL WALL COUNTER TOP COUNTER TOP
