A roof penetration detail featuring a vertical vent pipe passing through a roof assembly with rigid insulation and a roofing membrane. A vertical flashing membrane extends up the pipe and is secured with a draw band and continuous sealant at the top. The base of the flashing transitions horizontally over the roofing membrane with a metal collar and continuous sealant. The vertical penetration extends a minimum of twelve inches above the top of the roof.
CONTINUOUS SEALANT MINIMUM 12" TO TOP OF ROOF ROOF RIGID INSULATION ROOFING MEMBRANE MEMBRANE HORIZONTAL FLASHING METAL COLLAR VERTICAL FLASHING MEMBRANE DRAW BAND CONTINUOUS SEALANT VENT CONTINUOUS SEALANT SCALE: NTS 3 LAVATORY DOMESTIC WATER CONNECTION
