P-MR7GN — Uninsulated Pipe Thru Roof Detail

Plumbing · P-MR7GN

Uninsulated Pipe Thru Roof Detail

Units: imperial
Sheet: P-400
Discipline: Plumbing

Materials

Steel Stainless Steel

Elements

Roofs Waterproofing / Flashing

Connections

Welded Connection

Text on the drawing

CONTINUOUS WELD ALL AROUND PIPE STEEL CAP ROOF PIPE SLEEVE STAINLESS STEEL FLASHING 1" NO SCALE 7 UNINSULATED PIPE THRU ROOF DETAIL
