Self-regulating electric heat trace freeze protection is applied along piping with a power connection kit, thermostat, and end seals as indicated on drawings. A heat tracing controller connects to a 208-volt single-phase power supply and a wall-mounted outside air temperature sensor located per floor plans. Fiberglass cloth adhesive tape secures the heating cable, and pipe insulation is installed over the assembly according to project specifications.
RAYCHEM XL-TRACE SELF-REGULATING ELECTRIC HEAT TRACE FREEZE PROTECTION . APPLY AS INDICATED ON DRAWINGS. FURNISH WITH POWER CONNECTION KIT, GLASS ADHESIVE TAPE, THERMOSTAT, AND LABELS FOR A COMPLETE SYSTEM. SEE FLOOR PLANS FOR LOCATION OF WALL MOUNTED OUTSIDE AIR TEMPERATURE SENSOR POWER CONNECTION KIT HEAT TRACING CONTROLLER END SEAL END SEAL FIBERGLASS CLOTH ADHESIVE TAPE (TYP) PIPE INSULATION (SEE SPECIFICATIONS) SELF-REGULATING HEAT TRACING 208 VOLTS/1PH SEE ELECTRICAL DRAWINGS
