This interior door head detail shows a hollow metal door jamb set within a framed partition with a wood panel wall system. The hollow metal jamb is attached using a minimum of two number 8 sheet metal screws and features a gasket as scheduled. The adjacent wood panel wall system is integrated with a finish matching the door and jamb.
1/2" 2" 5/8" 1 15/16" 1 15/16" 6 1/4" WP-06 WOOD PANEL WALL SYSTEM DOOR TYPES AS SCHEDULED, FIN TO MATCH ADJ WOOD PNL HM DOOR JAMB, FIN TO MATCH ADJ WOOD PNL GESKET AS SCHEDULED ATTACH W/MIN (2) #8 STMS 1/2" PARTITION AS SCHED 2 1/2"
