A double cleanout assembly is installed with cast iron coil pipe risers and fittings rising to finish grade within paved or sidewalk areas. Each riser terminates with an iron ferrule and a brass countersunk screw plug flush with the surface. The entire assembly is surrounded by a concrete collar measuring eighteen inches wide and nine inches deep, reinforced with three-eighths-inch rebar and featuring a two-inch chamfer at the edges. Subgrade preparation requires ninety-five percent compaction beneath the collar and ninety percent compaction around the lower piping. A grouted plug is specified when the cleanout occurs at the end of the line.
IRON FERRULE WITH A BRASS COUNTER-SUNK SCREW PLUG 95% COMPACTION CAST IRON COIL PIPE RISER AND FILLING 9" 9" 9" FLOW GROUTED PLUG WHEN CLEANOUT OCCURES AT END OF LINE TRAVELED WAY SURFACING, SIDEWALK ROADWAY OR PARKING 4" DIA MAX 2" CHAMFER ON ALL COLLARS WITH EARTH FINISH GRADE 3/8" REBAR CONCRETE COLLAR 18" WIDE LENGTH VARIES W/ SIZE OF PIPE 90% COMPACTION
