An eight-inch storm drain riser connects through a one-foot diameter sleeve to a settlement vault provided by others. The point of connection to civil utilities sits at a bottom of pipe elevation of 9.17 feet mean sea level. The sleeve features a bottom of pipe elevation of 9.93 feet mean sea level and a finished floor elevation of 13.93 feet. Coordinate layout references direct further routing to sheet P-603.
SJ SD-1 8"SD POC TO CIVIL 8"SD UP SETTLEMENT VAULT BY OTHERS BOP 9.17 MSL 3 P-603 1 P-603 SD 3 1' - 0"Ø SLEEVE BOP 13.93 FF BOP 9.93 MSL
