A compressed air drop assembly starts from an overhead air drop line equipped with a ball valve and typical pipe support secured to a wall or structure. The vertical drop incorporates a dirt leg fitted with a concentric reducer and a bottom drain valve. An air filter and regulator with gauge are integrated into the line, extending horizontally to a quick coupler connector sized per specification located at 1250 above finished floor. An optional hard pipe connection to pneumatic equipment branches off as required.
15 DRAIN VALVE 20 X 150 DIRT LEG TYP. PIPE SUPPORT TO WALL OR STRUCTURE 20 X 15 CONCENTRIC REDUCER 20 AIR DROP BALL VALVE QUICK COUPLER CONNECTOR SIZE PER SPEC. @ 1250 AFF SEE ABOVE FOR PLAN VIEW OPTIONAL HARD PIPE TO PNEUMATIC EQUIPEMENT AS REQUIRED REGULATOR/GAUGE ELEVATION AIR FILTER TYPE 2
