The fine screen is mounted to the sluiceway using half-inch stainless steel bolts spaced at twelve inches on center all around. Assembly elevations are noted with the sluiceway centerline at elevation 30.50 and the top screen level at elevation 35.67. Connection details include a one-eighth inch fillet weld size designation and adjacent piping with variable elevations.
FINE SCREEN 1/2" O SST BOLTS @ 12" O.C. ALL AROUND EL 35.67 1 1/8 3-12 EL VARIES HP 30.05 SLICEWAY CL EL 30.50 F E D C B
