An underground utility trench is excavated into undisturbed earth and backfilled with compacted material matching adjacent soil conditions. A sand bedding layer is hand tamped in six-inch layers to twelve inches above the top and simultaneously on all sides of the pipes to maintain uniform pressure. The trench accommodates a new gas pipe, nitrous oxide and oxygen pipes inside polyethylene plastic pipe conduits, and fuel oil piping, maintaining specified minimum horizontal clearances and code-required burial depths.
GRADE NOTE: 1. EXCAVATE TRENCH TO WIDTH AND DEPTH REQUIRED. SHORE UP TRENCH OR LAY BACK AS SPECIFIED. 2. NO COVERAGE OF TRENCHING IS PERMITTED UNTIL INSPECTED AND APPROVED BY OWNER. 3. MIN CODE DEPTHS CAN BE REDUCED IF THE PIPING IS SHIELDED, SEE NFPA 99 & CPC. 4. WORK UNDER OSHPD PROJECT #XXXX. 4"MIN 6" MIN 12" MIN SAND BEDDING. HAND TAMP IN 6" LAYERS TO 12" ABOVE TOP AND SIMULTANEOUSLY ON ALL SIDES OF PIPES TO MAINTAIN UNIFORM PRESSURE PIPE MARKER (TYPICAL) NEW GAS PIPE UNDISTURBED EARTH COMPACTED BACKFILL TO MATCH ADJACENT SOIL CONDITION CODE 36" MIN EXCAVATE TO WIDTH AND DEPTH REQUIRED. SHORE UP TRENCH OR LAY BACK AS SPECIFIED CODE 18" MIN 6" MIN NO 2 PIPE IN POLYETHYLENE (PE) PLASTIC PIPE CONDUIT O 2 PIPE IN POLYETHYLENE (PE) PLASTIC PIPE CONDUIT 12" MIN 4" 6" 4" 6 FT. 6" MIN 36" MIN. FUEL OIL PIPING. 4 4 4
