This drawing outlines the spatial relationship and concrete encasement requirements for piping passing near or under building foundations. Piping crossing within three feet below the bottom of a footing must be encased in concrete, extending at least six inches under and eighteen inches wider than the sleeve across the full width of the footing. Trench excavation lines must maintain a minimum slope and clearance, with the contractor responsible for shoring and sheathing to prevent caving until backfill is complete. Penetrating pipes enter through sleeves and are caulked as required. Structural drawings take precedence if discrepancies arise.
3 10 FT MIN 1 2 2 2 FT MIN 1 9" 1 2 MIN 6" THE CONTRACTOR SHALL BE RESPONSIBLE FOR SHORING SHEATHING, OR OTHERWISE MAINTAINING THE SIDES OF TRENCH FROM CAVING UNTIL BACKFILL IS COMPLETE. PIPING CROSSING UNDER AND NOT MORE THAN 3' BELOW THE BOTTOM OF THE NORMAL FOOTING SHALL BE ENCASED IN CONCRETE: NOT LESS THAN 6" UNDER AND 18" WIDER THAN SLEEVE & FULL WIDTH OF FOOTING. VERIFY THIS DETAIL WITH SIMILAR DETAIL ON THE STRUCTURAL DWGS. IF DETAIL IS DIFFERENT, STRUCTURAL DETAIL SHALL BE FOLLOWED. BOTTOM OF TRENCH EXCAVATION SHALL NOT EXTEND BELOW LINES 18" WIDER THAN CASING & FULL WIDTH OF FOOTING ENTER PIPES & CAULK AS REQ'D PIPE SLEEVE (TYP) SCALE: NOT TO SCALE 7 PIPE THRU WALL DETAIL
