An outdoor gas pressure regulator connects to a rooftop air conditioning unit via a full-sized gas line passing through a rubber grommet at the unit housing. The assembly incorporates a gas pressure regulator with a vent tube connector and quarter-inch tubing, a full-sized capped inspection tee, and a dirt leg with a full-sized capped tee. A gas cock is installed on the supply line, which is elevated above the roof line using a roof pipe support spaced at a minimum of ten times the pipe diameter.
10X PIPE DIA. (MIN.) ROOF PIPE SUPPORT. SEE DETAIL. DIRT LEG ROOF LINE FULL SIZED CAPPED TEE RUBBER GROMMET ROOF TOP AIR CONDITIONING UNIT RUN GAS LINE FULL SIZE TO AIR CONDITIONING UNIT GAS PRESSURE REGULATOR VENT TUBE CONNECTOR WITH 1/4" TUBING GAS COCK FULL SIZE CAPPED INSPECTION TEE
