An elevator sump pump sits within a minimum twenty-four by twenty-four by twenty-four inch sump in the elevator pit floor. A two-inch pump discharge line routes upward with a union and check valve. An oil sensor is connected near the pump alongside a power cable with a three-prong plug up to six feet long. The system connects to a non-GFCI receptacle, a means of disconnect, and a junction box for pump controls. Separate conduits for power and controls extend to an exterior pump control panel located outside the elevator shaft. A four-inch hub drain with a twenty-four-inch standpipe and trap primer is positioned adjacent to the pit.
PUMP CONTROL PANEL LOCATED EXTERIOR TO ELEVATOR SHAFT CONDUIT AND WIRING FOR PUMP POWER AND CONTROLS. PROVIDE SEPARATE CONDUITS FOR POWER AND CONTROLS. COORDINATE WITH DIV. 26 CONTRACTOR TO PROVIDE CONDUIT, JUNCTION BOXES AND POWER RECEPTACLE FOR PUMP. 2" PUMP DISCHARGE UNION CHECK VALVE ELEVATOR PIT FLOOR ELEVATOR SUMP PUMP IN MINIMUM 24"X24"X24" SUMP. REFER TO SCHEDULES FOR CAPACITY. OIL SENSOR TRAP PRIMER 4" HUB DRAIN WITH 24" STANDPIPE FFE=XXX.XX' JUNCTION BOX FOR PUMP CONTROLS NON-GFCI RECEPTACLE FOR PUMP POWER AND MEANS OF DISCONNECT PUMP POWER CABLE WITH 3-PRONG PLUG END. 6 FOOT MAXIMUM CABLE LENGTH.
