A drain pipe terminates above a floor sink, maintaining a minimum one-inch air gap between the bottom of the drain pipe and the floor sink rim. The floor sink is positioned at the end of the drainage line.
REDUCING VALVE AND STRAINER WITH PRESSURE GAUGE FITTING) DRAIN PIPE MAINTAIN 1" MIN. GAP BETWEEN DRAIN PIPE AND FLOOR SINK FLOOR SINK AT THE END OF THE LINE 12" = 1'-0" 7 FLOOR CLEANOUT DETAIL
