A test tee installed in a plumbing stack connects to a threaded cleanout plug and aligns flush with the finished wall surface through a stainless steel round access cover and screw. A mounting height chart specifies centerline installation elevations for urinals, lavatories, sinks, and general wall locations. Heights must be coordinated with the architect prior to installation if deviations from the schedule are required.
FINISHED WALL ROUND ACCESS STAINLESS STEEL COVER AND SCREW. CLEANOUT TEST TEE PLUG THREADED CL SURFACE COORDINATE WITH ARCHITECT PRIOR TO INSTALLING AT A HEIGHT OTHER THAN THAT LISTED ABOVE. CENTERLINE MOUNTING HEIGHT CHART DESCRIPTION URINAL SINK LAVATORY GENERAL WALL LOCATION NOTE: 12" 12" 48" HEIGHT 12"
