Domestic Water Pressure Reducing Station Assembly

About this detail

Incoming two and one-half inch cold water supply from below branches into parallel circuits controlled by ball valves and pressure reducing valves with strainers. The primary branch features an all-bronze pressure reducing valve set at eighty pounds per square inch, while the secondary branch is equipped with an all-bronze pressure reducing valve set at seventy pounds per square inch and a three-quarter inch line. Each pressure reducing assembly incorporates upstream and downstream ball valves for isolation, integrated pressure gauges, and tagged water pressure valve identifiers. The regulated lines rejoin into a two and one-half inch cold water supply line feeding the building when street pressure exceeds eighty pounds per square inch.
