A twenty-four by twenty-four inch hot dip galvanized pour frame is embedded directly into the concrete pump discharge pit and secured with three-eighths by four-inch long J-anchor bolts spaced at a maximum of eight inches on center with a minimum of three inches per side for a square sump. A one-quarter inch fillet weld connects the frame elements. A nineteen-W-four steel bar grating featuring one-eighth inch bars rests within the frame opening.
DETAIL A PUMP DISCHARGE FRAME COMPLETED WITH 3 8 "X4" LONG J-ANCHIR BOLT MAX 8"O.C. MIN. 3" PER SIDE FOR SQUARE SUMP 19-W-4 STEEL BAR GRATING, 1X 1 8 " BAR BY GRATING PACIFIC OR EQUAL 24"X24" HOT DIP GALVANIZED "E-Z" POUR FRAME EMBEDDED IN CONCRETE 14
