Suspended pipes rest on roller stands mounted to a trapeze member secured by hanger rods and locking nuts. Uninsulated and insulated pipes are accommodated, with vapor barrier insulation specified on select runs. A fourteen gauge insulation shield at least eighteen inches long protects the insulation at the support points, supplemented by a pipe saddle at least eighteen inches long. Roller stands are bolted directly to the support member with a maximum center-to-center spacing of forty-two inches.
℄ TO ℄ MAX. SPACING 42" VAPOR BARRIER INSULATION PIPE HANGER ROD PIPE SADDLE AT LEAST 18" LONG LOCKING NUT BOLT PIPE ROLLER TO SUPPORT PIPE NO INSULATION ROLLER STAND 14 GAUGE INSULATION SHIELD MIN. 18" LONG INSULATION (NOT VAPOR BARRIER)
