Condensate piping is supported by an electro-galvanized pipe clamp and bolt secured to an electro-galvanized strut channel. The strut channel rests on a B-Line series C or CE pipe support spaced on six-foot centers. The pipe support sits on a J-walk roof friction pad installed on a bed of roof mastic over the roofing assembly.
