A concrete sump pit features minimum clear inside dimensions of twenty-four by twenty-four by thirty inches, with six-inch thick walls on all four sides anchored using epoxy dowels. Interior surfaces are lined with a Dex-O-Tex M-E flooring waterproofing seal and a Dex-O-Tex vapor control 200 coating, backed by an exterior waterproof membrane. A dewatering pump is positioned inside the pit with a pump switch, plugging into an electrical receptacle above, and a cut grate opening accommodates the discharge pipe.
ELEVATION 24" DETAIL A 24"X24"X30" CLEAR INSIDE PIT CUT GRATE OPENING FOR DISCHARGE PIPE PROVIDE A DEX-O-TEX M-E FLOORING WATERPROOFING SEAL IN THE INTERIOR SURFACE OF THE PIT. PROVIDE A DEX-O-TEX VAPOR CONTROL 200 COATING. DEWATERING PUMP TO ELECTRICAL RECEPTACLE SUMP PIT MIN. SIZE: 24"x24"x30" PUMP SWITCH 6" WALL, TYP 4 SIDES EPOXY DOWELS WATERPROOF MEMBRANE
