A water hammer arrestor connects to a three-quarter-inch or one-inch riser pipe using a threaded end connection. An isolation valve installs directly above the riser with a fitting adapter linking the valve to the arrestor body.
3/4" OR 1" RISER FITTING ADAPTER ISOLATION VALVE THREADED END CONNECTION WATER HAMMER ARRESTOR
