A solid aluminum canopy with a painted finish matching MTL-16 is provided by others and secured with a metal anchor bracket. The assembly features a decorative face veneer on three sides and uses two clear braided cords spaced one inch apart for suspension or stabilization.
DECORATIVE FACE VENEER ON 3 SIDES 2X CLEAR BRAIDED CORD SOLID ALUMINUM CANOPY,PAINTED FINISH TO MATCH MTL-16, PROVIDED BY OTHERS MTL ANCHOR BRACKET 1"
