An in-line circulating pump is installed in the domestic water piping with a gate or ball valve and a check valve on the discharge side for flow control. Unions are placed adjacent to the pump and valves to facilitate maintenance and removal. A dial type pressure gauge ranging from zero to one hundred PSIG with a gauge cock is connected via a reducing tee on both the suction and discharge sides of the pump. An aquastat is installed on the piping for automated control of the pump operation.
FLOW CHECK VALVE FOR CONTINUATION & SIZE, SEE P-401 GATE (OR BALL)VALVE DIAL TYPE PRESSURE GAUGE (0-100 PSIG) IN-LINE CIRCULATING PUMP (SEE PUMP SCHEDULE ON P-601) GAUGE COCK UNION REDUCING TEE (OR TEST PLUG FOR INSERTION OF GAUGE) AQUASTAT FOR CONTROL OF PUMP
