A floor sink is recessed within a two-foot square concrete blockout, set flush with the finished floor line. A flashing clamp secures waterproofing around the drain body. The drain features a full grate unless otherwise scheduled, with a dome strainer or sediment bucket fitted inside. The outlet requires a minimum two-inch connection, transitioning via a two-inch by three-inch reducer for combination waste and vent systems. No-hub clamps connect the piping to a three-inch minimum waste line.
FLASHING CLAMP FLOOR LINE 3" WASTE MINIMUM AND VENT SYSTEM COMBINATION WASTE 2" FLOOR SINKS FOR REQUIRED FOR ALL 2" x 3" REDUCER DRAIN BODY 2'-0" x 2'-0" BLOCKOUT OR SPECIFIED NO HUB CLAMP (TYP.) FLOOR SINK OUTLET DOME STRAINER OR (2" MINIMUM) FLUSH WITH FLOOR OTHERWISE SCHEDULED FULL GRATE UNLESS SEDIMENT BUCKET PER SCHEDULE
