Top view and side section of a multi-compartment interceptor tank assembly. The top view details three twenty-four-inch cast iron frames and covers with gastight gaskets. The side section shows standard four-inch pipe and fittings, inlet and outlet invert elevations, and optional three, six, and twelve-inch grade rings used for height adjustment. Access openings and internal baffling or piping configurations are dimensioned relative to the tank body.
X'-X" X'-X" TOP VIEW 24" X'-X" X'-X" X'-X" INLET INVERT INVERT OUTLET X'-X" 24" CAST IRON FRAMES AND COVERS WITH GASKET (GASTIGHT) 3 TOTAL 4" PIPE AND FITTINGS STANDARD 2'-6" TO 7'-6" 3", 6" AND 12" GR2432 GRADE RINGS AS REQUIRED AT EXTRA COST PLUG
